| Číslo dielu | HJ080IA-01F |
| Značka | Innolux |
| Veľkosť | 8.0 |
| Aplikácia | DPF |
| Rozhodnutie | 1024×768 |
| Zloženie | LCM |
| Jas | 350 |
| CR | 800:1 |
| Farby | 262K/16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | CHIMEI INNOLUX |
| panelový model | HJ080IA-01F |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 8.0 inch |
| rozhodnutie | 1024(RGB)×768 , XGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 162.048×121.536 mm |
| obrys | 174×136×2.65 mm |
| povrch | Hard coating |
| jas | 350 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR＞10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 3S9PWLEDWithout Driver |
| signálové rozhranie | LVDS (1 ch, 6/8-bit), 40 pins |
| vstupné napätie | 3.3/10/18.9/-7.8V (VCC/AVDD/VGH/VGL) |
| aplikácie | DPF |
