| Číslo dielu | LTE700WQ-F05 |
| Značka | Samsung |
| Veľkosť | 7.0 |
| Aplikácia | DPF |
| Rozhodnutie | 480×234 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 500:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | TTL |
| značka panelu | SAMSUNG |
| panelový model | LTE700WQ-F05 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 480×234(RGB) |
| režim zobrazenia | TN, Normally White, TMR |
| aktívna oblasť | 154.08×86.58 mm |
| obrys | 166×100×7.2 mm |
| povrch | |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 500 : 1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 13/17 (Typ.)(Tr/Td) |
| pozorovací uhol | 65/65/55/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 8-bit), 40 pins |
| vstupné napätie | 2.5/3.3V (Typ.)(VDD) |
| aplikácie | DPF |
