| Číslo dielu | AT080TN64 |
| Značka | Innolux |
| Veľkosť | 8.0 |
| Aplikácia | CNS |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 500:1 |
| Farby | 262K/16.2M |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | INNOLUX |
| panelový model | AT080TN64 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 8.0 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 176.64×99.36 mm |
| obrys | 192.8×116.9 mm |
| povrch | Antiglare |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 262K/16.2M (6-bit / 6-bit + Dithering), CIE193150% |
| Doba odozvy | 10/15 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 3S12PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6/8-bit), 50 pins |
| vstupné napätie | 3.3/10.4/16.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikácie | CNS |
| AT080TN01 | Innolux | 8.0 | 800×480 |
| AT080TN03 V.1 | Innolux | 8.0 | 800×480 |
| AT080TN03 V.2 | Innolux | 8.0 | 800×480 |
| AT080TN03 V.7 | Innolux | 8.0 | 800×480 |
| AT080TN42 | Innolux | 8.0 | 800×600 |
| AT080TN42 V.1 | Innolux | 8.0 | 800×600 |
| AT080TN43 | Innolux | 8.0 | 800×600 |
| AT080TN52 | Innolux | 8.0 | 800×600 |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| AT080TN64 | Innolux | 8.0 | 800×480 |
| AM-480272-043D | Other | 4.3 | 480×272 |
| AT101WSM-NW0-3800(3900) | BOE | 10.1 | 1024×600 |
| C070FW02 V2 | AUO | 7.0 | 480×234 |
| C070VW04 V5 | AUO | 7.0 | 800×480 |
| CLAA070LFA1 CW | CPT | 7.0 | 800×480 |
| CLAA070NJ07CW | CPT | 7.0 | 1024×600 |
| EDTCB18QEF | TOSHIBA | 7.0 | 800×480 |
| G070Y2-T02 | Innolux | 7.0 | 800×480 |
| LQ101K5DZ01 | SHARP | 10.1 | 1280×422 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
