| Číslo dielu | LQ055T3SX04 |
| Značka | SHARP |
| Veľkosť | 5.5 |
| Aplikácia | MPH |
| Rozhodnutie | 1080×1920 |
| Zloženie | CELL |
| Jas | 0 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | No B/L |
| Rozhranie | |
| značka panelu | SHARP |
| panelový model | LQ055T3SX04 |
| typ panelu | IGZO TFT-LCD , CELL |
| veľkosť panelu | 5.5 inch |
| rozhodnutie | 1080(RGB)×1920 , FHD |
| režim zobrazenia | New Mode2, Normally Black, Transmissive |
| aktívna oblasť | 68.04×120.96 mm |
| obrys | 70.84×128.16 mm |
| povrch | |
| hĺbka skla | 0.20+0.20 mm |
| priepustnosť | 4.2% (Typ.)(with Polarizer) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193170% |
| Doba odozvy | 35 (Max.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| vodič ic | COG Built-in NT35532 |
| aplikácie | MPH |
