| Číslo dielu | LS055R1SC01 |
| Značka | SHARP |
| Veľkosť | 5.5 |
| Aplikácia | MPH |
| Rozhodnutie | 1440×2560 |
| Zloženie | LCM |
| Jas | 480 |
| CR | 1300:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | SHARP |
| panelový model | LS055R1SC01 |
| typ panelu | CG-Silicon , LCM |
| veľkosť panelu | 5.5 inch |
| rozhodnutie | 1440(RGB)×2560 , Quad-HD |
| režim zobrazenia | New Mode2, Normally Black, Transmissive |
| aktívna oblasť | 68.04×120.96 mm |
| obrys | 70.87×128.45×1.45 mm |
| povrch | Hard coating (3H) |
| jas | 480 cd/m² (Typ.) |
| kontrastný pomer | 1300:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193170% |
| Doba odozvy | 35 (Max.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhranie | MIPI (2 ch, 4 data lanes), 45 pins |
| vstupné napätie | 1.8/5.75/-5.75V (Typ.)(IOVDD/AVDD+/AVDD-) |
| aplikácie | MPH |
| H546DLB01.1 | AUO | 5.5 | 1080×1920 |
| LQ055K3SX02 | SHARP | 5.5 | 720×1280 |
| LQ055T3SX02 | SHARP | 5.5 | 1080×1920 |
| LS055R1SC01 | SHARP | 5.5 | 1440×2560 |
| LS055R1SX03 | SHARP | 5.5 | 1440×2560 |
| LS055R1SX04 | SHARP | 5.5 | 1440×2560 |
| LS055T1SX01 | SHARP | 5.5 | 1080×1920 |
| LS055T3SX05 | SHARP | 5.5 | 1080×1920 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| UG-5664ASYGF01 | WiseChip | 5.5 | 256×64 |
| AMS347FF01 | Samsung | 3.5 | 360×640 |
| H320QN01 V2 | AUO | 3.2 | 320×480 |
| H572DAN01.2 | AUO | 5.7 | 1080×1920 |
| LH350H01-FD01-A41 | LG Display | 3.5 | 320×480 |
| LH430WV3-SH02 | LG Display | 4.3 | 480×800 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS035Y8DX02A | SHARP | 3.5 | 480×800 |
| TD035SHED1 | TPO | 3.5 | 480×640 |
| TM022HDHT1-05 | Tianma | 2.2 | 240×320 |
| TP241MC01G | Neoview Kolon | 2.4 | 240×320 |
