| Číslo dielu | H466TAN01.0 |
| Značka | AUO |
| Veľkosť | 4.7 |
| Aplikácia | MPH |
| Rozhodnutie | 720×1280 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 900:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | AUO |
| panelový model | H466TAN01.0 |
| typ panelu | LTPS TFT-LCD , LCM |
| veľkosť panelu | 4.7 inch |
| rozhodnutie | 720(RGB)×1280 , WXGA |
| režim zobrazenia | AHVA, Normally Black, Transmissive |
| aktívna oblasť | 58.104×103.296 mm |
| obrys | 61.92×114.38×1.75 mm |
| povrch | |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 900:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193170% |
| Doba odozvy | 35 (Max.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhranie | MIPI (3 data lanes), 25 pins |
| aplikácie | MPH |
| G321EV5R000 | SII | 4.7 | 320×240 |
| H466TAN01.0 | AUO | 4.7 | 720×1280 |
| H466TAN01.1 | AUO | 4.7 | 720×1280 |
| H466TAN02.4 | AUO | 4.7 | 720×1280 |
| KCG047QV1AA-A21 | Kyocera | 4.7 | 320×240 |
| LM32K101 | SHARP | 4.7 | 320×240 |
| LS047T1SC01K | SHARP | 4.7 | 1080×1920 |
| LS047T1SC02 | SHARP | 4.7 | 1080×1920 |
| TM047XDZP02 | Tianma | 4.7 | 540×960 |
| TS047NAARB01-00 | Tianma | 4.7 | 480×272 |
| H347QVN02.0 | AUO | 3.5 | 320×480 |
| HVA37WV1-M02 | HYDIS | 3.7 | 480×800 |
| LQ024B7UD01 | SHARP | 2.4 | 160×240 |
| LS038Y3LX01 | SHARP | 3.8 | 480×800 |
| LS043T1LX01A | SHARP | 4.3 | 540×960 |
| LS047T1SC02 | SHARP | 4.7 | 1080×1920 |
| LS050T1SX10 | SHARP | 5.0 | 1080×1920 |
| LS055R1SX03 | SHARP | 5.5 | 1440×2560 |
| TM022HDHT1-00 | Tianma | 2.2 | 240×320 |
| TM024HDH36 | Tianma | 2.4 | 240×320 |
