| Číslo dielu | LH350H02-FD02 |
| Značka | LG Display |
| Veľkosť | 3.5 |
| Aplikácia | MPH |
| Rozhodnutie | 320×480 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 150:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | LG Display |
| panelový model | LH350H02-FD02 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 3.5 inch |
| rozhodnutie | 320(RGB)×480 , HVGA |
| režim zobrazenia | TN, Normally White, Transflective |
| aktívna oblasť | 49.92×74.88 mm |
| obrys | 55.14×82.84×1.85 mm |
| povrch | |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 150:1 (Typ.)(Transmissive)7:1 (Typ.)(Reflective) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| Doba odozvy | 30 (Typ.)(Tr+Td) |
| pozorovací uhol | 50/50/50/45 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 6S1PWLEDWithout Driver |
| signálové rozhranie | MIPI (2 data lanes), 20 pins |
| vstupné napätie | 3.0/5.672/1.8V (Typ.)(VDDC/VDDA/LOVCC) |
| aplikácie | MPH |
