| Číslo dielu | H546TAN01.0 |
| Značka | AUO |
| Veľkosť | 5.5 |
| Aplikácia | MPH |
| Rozhodnutie | 720×1280 |
| Zloženie | LCM |
| Jas | 440 |
| CR | 800:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | AUO |
| panelový model | H546TAN01.0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.5 inch |
| rozhodnutie | 720(RGB)×1280 , WXGA |
| režim zobrazenia | AHVA, Normally Black, Transmissive |
| aktívna oblasť | 68.04×120.96 mm |
| obrys | 72.3×130.39×1.75 mm |
| povrch | |
| jas | 440 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193170% |
| Doba odozvy | 35 (Max.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhranie | MIPI (4 data lanes) |
| vstupné napätie | 1.8/2.8V (Typ.)(IOVCC/VCI) |
| aplikácie | MPH |
