| Číslo dielu | LM300WQ6-SLA1 |
| Značka | LG Display |
| Veľkosť | 30.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 2560×1600 |
| Zloženie | LCM |
| Jas | 350 |
| CR | 1000:1 |
| Farby | 1.07B |
| Podsvietenie | GB-r LED |
| Rozhranie | LVDS |
| značka panelu | LG Display |
| panelový model | LM300WQ6-SLA1 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 30.0 inch |
| rozhodnutie | 2560(RGB)×1600 , WQXGA |
| režim zobrazenia | AH-IPS, Normally Black, Transmissive |
| aktívna oblasť | 641.28×400.8 mm |
| obrys | 677.3×436.8 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 350 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 1.07B (10-bit), Adobe104% |
| Doba odozvy | 7/7 (Typ.)(Tr/Td); 6 (Typ.)(G to G) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | GB-r LEDWithout Driver |
| signálové rozhranie | LVDS (4 ch, 10-bit), 92 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | DMPC |
