| Číslo dielu | M170XW01 V3 |
| Značka | AUO |
| Veľkosť | 17.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1280×768 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 800:1 |
| Farby | 16.2M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | M170XW01 V3 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 17.0 inch |
| rozhodnutie | 1280(RGB)×768 , WXGA |
| režim zobrazenia | MVA, Normally Black, Transmissive |
| aktívna oblasť | 370.56×222.336 mm |
| obrys | 404×248.5×17.8 mm |
| povrch | Glare (Haze 0%), Hard coating (2H) |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 16.2M (6-bit + FRC) |
| Doba odozvy | 15/10 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR＞10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (1 ch, 8-bit), 20 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
