| Číslo dielu | VVX10F011B00 |
| Značka | Panasonic |
| Veľkosť | 10.1 |
| Aplikácia | PAD |
| Rozhodnutie | 1920×1200 |
| Zloženie | LCM |
| Jas | 650 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | eDP |
| značka panelu | Panasonic |
| panelový model | VVX10F011B00 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1920(RGB)×1200 , WUXGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 217.44×135.9 mm |
| obrys | 228.86×152.5×4.18 mm |
| povrch | Hard coating, Antireflection |
| jas | 650 cd/m² (Min.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| Doba odozvy | 35 (Max.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 10S6PWLEDEmbedded (LED Driver) |
| signálové rozhranie | eDP (2 Lanes), 30 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
