| Číslo dielu | AM-19201200B1TZQW-T00 |
| Značka | AMPIRE |
| Veľkosť | 10.1 |
| Aplikácia | IA |
| Rozhodnutie | 1920×1200 |
| Zloženie | LCM |
| Jas | 850 |
| CR | 800:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | AMPIRE |
| panelový model | AM-19201200B1TZQW-T00 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1920(RGB)×1200 , WUXGA |
| režim zobrazenia | Normally Black, Transmissive |
| aktívna oblasť | 216.806×135.504 mm |
| obrys | 232.65×155.2 mm |
| povrch | |
| jas | 850 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC), CIE193153% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (2 ch, 8-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | IA |
