| Číslo dielu | VVX10F002A00 |
| Značka | Panasonic |
| Veľkosť | 10.1 |
| Aplikácia | PAD |
| Rozhodnutie | 1920×1200 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | Panasonic |
| panelový model | VVX10F002A00 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1920(RGB)×1200 , WUXGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 217.44×135.9 mm |
| obrys | 227.1×147.1×4.13 mm |
| povrch | Hard coating, Antireflection |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| Doba odozvy | 30 (Max.)(Tr/Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6S6PWLEDEmbedded (LED Driver) |
| signálové rozhranie | MIPI (4 data lanes), 40 pins |
| vstupné napätie | 3.7V (Typ.) |
| aplikácie | PAD |
