| Číslo dielu | B101UAN07.0 |
| Značka | AUO |
| Veľkosť | 10.1 |
| Aplikácia | PAD |
| Rozhodnutie | 1200×1920 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | AUO |
| panelový model | B101UAN07.0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1200(RGB)×1920 , WUXGA |
| režim zobrazenia | AHVA, Normally Black, Transmissive |
| aktívna oblasť | 135.36×216.576 mm |
| obrys | 143×227.93×4.3 mm |
| povrch | Glare (Haze 0%) |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193172% |
| Doba odozvy | 25 (Typ.)(Tr+Tf) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 8S4PWLEDWithout Driver |
| signálové rozhranie | MIPI (4 data lanes), 45 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
| B101UAN01.1 | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW0A | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW1A | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW2A | AUO | 10.1 | 1920×1200 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| B101UAN02.1 | AUO | 10.1 | 1920×1200 |
| B101UAN07.0 | AUO | 10.1 | 1200×1920 |
| B101UAN07.2 | AUO | 10.1 | 1200×1920 |
| B101UAT02.1 | AUO | 10.1 | 1920×1200 |
| B080XAN02.0 | AUO | 7.9 | 768×1024 |
| B101EAN01.4 | AUO | 10.1 | 1280×800 |
| B116HAN03.1 | AUO | 11.6 | 1920×1080 |
| B116HAT03.1 | AUO | 11.6 | 1920×1080 |
| BP096WX1-100 | BOE | 9.6 | 800×1280 |
| CLAA101WJ01 | CPT | 10.1 | 1366×768 |
| LP079QX1-SP0V | LG Display | 7.9 | 1536×2048 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| P070ACB-DB1 | Innolux | 7.0 | 600×1024 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
