| Číslo dielu | TM090JDH01 |
| Značka | Tianma |
| Veľkosť | 9.0 |
| Aplikácia | PAD |
| Rozhodnutie | 1280×800 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 700:1 |
| Farby | 262K/16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | TIANMA |
| panelový model | TM090JDH01 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 9.0 inch |
| rozhodnutie | 1280(RGB)×800 , WXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 193.92×121.2 mm |
| obrys | 206.76×135.06×4.8 mm |
| povrch | |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 700:1 (Typ.) |
| zobraziť farby | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193170% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 3S12PWLEDWithout Driver |
| signálové rozhranie | LVDS (1 ch, 6/8-bit), 51 pins |
| vstupné napätie | 3.3/11/20/-6.8V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikácie | PAD |
