| Číslo dielu | HSD090ICW1-A00 |
| Značka | HannStar |
| Veľkosť | 9.0 |
| Aplikácia | DPF |
| Rozhodnutie | 640×234 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 500:1 |
| Farby | |
| Podsvietenie | WLED |
| Rozhranie | Analog |
| značka panelu | HannStar |
| panelový model | HSD090ICW1-A00 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 9.0 inch |
| rozhodnutie | 640(RGB)×234 |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 197.76×111.735 mm |
| obrys | 210.7×126.4×4.25 mm |
| povrch | |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | , CIE193145% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 70/70/65/65 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 3S8PWLEDWithout Driver |
| signálové rozhranie | TFT Specific Analog RGB, 26 pins |
| vstupné napätie | 3.3/5/15/-10V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikácie | DPF |
