| Číslo dielu | B101UAN01.9 |
| Značka | AUO |
| Veľkosť | 10.1 |
| Aplikácia | PAD |
| Rozhodnutie | 1920×1200 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 600:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | B101UAN01.9 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1920(RGB)×1200 , WUXGA |
| režim zobrazenia | AHVA, Normally Black, Transmissive |
| aktívna oblasť | 216.81×135.5 mm |
| obrys | 242.44×148.15×4.7 mm |
| povrch | Antiglare |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 600:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC), CIE193152% |
| Doba odozvy | 15/10 (Typ.)(Tr/Td) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (2 ch, 8-bit), 50 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
