| Číslo dielu | LQ097L1JY01A |
| Značka | SHARP |
| Veľkosť | 9.7 |
| Aplikácia | PAD |
| Rozhodnutie | 2048×1536 |
| Zloženie | LCM |
| Jas | 440 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | eDP |
| značka panelu | SHARP |
| panelový model | LQ097L1JY01A |
| typ panelu | IGZO TFT-LCD , LCM |
| veľkosť panelu | 9.7 inch |
| rozhodnutie | 2048(RGB)×1536 , QXGA |
| režim zobrazenia | O-mode FFS, Normally Black, Transmissive |
| aktívna oblasť | 196.608×147.456 mm |
| povrch | Glare (Haze 0%), Hard coating (2H), Reflection 1.45% (Max.) |
| jas | 440 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193172% |
| Doba odozvy | |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 7S6P×2CNWLEDWithout Driver |
| signálové rozhranie | eDP (4 Lanes), 56 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
