| Číslo dielu | P101KDA-AP1 |
| Značka | Innolux |
| Veľkosť | 10.1 |
| Aplikácia | PAD |
| Rozhodnutie | 1200×1920 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | INNOLUX |
| panelový model | P101KDA-AP1 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1200(RGB)×1920 , WUXGA |
| režim zobrazenia | AAS, Normally Black, Transmissive |
| aktívna oblasť | 135.36×216.576 mm |
| obrys | 143×227.93×4.3 mm |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193170% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 4 stringsWLEDWithout Driver |
| signálové rozhranie | MIPI (4 data lanes), 45 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
