| Číslo dielu | LPM089A001A |
| Značka | JDI |
| Veľkosť | 8.9 |
| Aplikácia | PAD |
| Rozhodnutie | 2560×1600 |
| Zloženie | LCM |
| Jas | 500 |
| CR | 1200:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | JDI |
| panelový model | LPM089A001A 2 Compatible model |
| typ panelu | LTPS TFT-LCD , LCM |
| veľkosť panelu | 8.9 inch |
| rozhodnutie | 2560(RGB)×1600 , WQXGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 192×120 mm |
| obrys | 197.6×129.6×3.43 mm |
| povrch | |
| jas | 500 cd/m² (Typ.) |
| kontrastný pomer | 1200:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193172% |
| Doba odozvy | |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6S6PWLEDWithout Driver |
| signálové rozhranie | MIPI (2 ch, 4 data lanes), 61 pins |
| vstupné napätie | 1.8/3.3V (Typ.)(VDDIO/VBAT) |
| aplikácie | PAD |
