| Číslo dielu | NL2432DR22-11B |
| Značka | NLT |
| Veľkosť | 3.5 |
| Aplikácia | PDA |
| Rozhodnutie | 240×320 |
| Zloženie | LCM |
| Jas | 50 |
| CR | |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | NEC |
| panelový model | NL2432DR22-11B |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 3.5 inch |
| rozhodnutie | 240(RGB)×320 , QVGA |
| režim zobrazenia | TN, Normally White, Reflective |
| aktívna oblasť | 53.64×71.52 mm |
| obrys | 66.2×91×4.7 mm |
| povrch | Hard coating (3H) |
| jas | 50 cd/m² (Typ.) |
| kontrastný pomer | 10/10(Reflective) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 15/17 (Typ.)(Tr/Td) |
| pozorovací uhol | |
| typ lampy | 2S2PWLED |
| signálové rozhranie | CMOS (1 ch, 6-bit), 45 pins |
| vstupné napätie | 3.0/5.25/15.0/-15.0V (Typ.)(VCC/VDD/VGON/VGOFF) |
| aplikácie | PDA |
