| Číslo dielu | PT035TN01 V.6 |
| Značka | Innolux |
| Veľkosť | 3.5 |
| Aplikácia | PND |
| Rozhodnutie | 320×240 |
| Zloženie | LCM |
| Jas | 350 |
| CR | 300:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | Parallel/Serial |
| značka panelu | INNOLUX |
| panelový model | PT035TN01 V.6 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 3.5 inch |
| rozhodnutie | 320(RGB)×240 , QVGA |
| režim zobrazenia | TN, Normally White, TMR |
| aktívna oblasť | 70.08×52.56 mm |
| obrys | 78.2×65×4.8 mm |
| povrch | Antiglare |
| jas | 350 cd/m² (Typ.) |
| kontrastný pomer | 300 : 1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 15/20 (Typ.)(Tr/Td) |
| pozorovací uhol | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6S1PWLEDWithout Driver |
| signálové rozhranie | Digital RGB (8/24-bit) + SPI, CCIR601/656, 60 pins |
| vstupné napätie | 3.3/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikácie | PND |
