| Číslo dielu | LS037V7DD05 |
| Značka | SHARP |
| Veľkosť | 3.7 |
| Aplikácia | PDA |
| Rozhodnutie | 480×640 |
| Zloženie | LCM |
| Jas | 130 |
| CR | 100:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | SHARP |
| panelový model | LS037V7DD05 |
| typ panelu | CG-Silicon , LCM |
| veľkosť panelu | 3.7 inch |
| rozhodnutie | 480(RGB)×640 , VGA |
| režim zobrazenia | TN, Normally White, Transflective |
| aktívna oblasť | 56.16×74.88 mm |
| obrys | 65×90.4 mm |
| povrch | Hard coating (3H) |
| jas | 130 cd/m² (Typ.) |
| kontrastný pomer | 100:1 (Typ.)(Transmissive)2.5:1 (Typ.)(Reflective) |
| zobraziť farby | 262K (6-bit), CIE193122% |
| Doba odozvy | 20/20 (Typ.)(Tr/Td) |
| pozorovací uhol | 40/40/40/40 (Typ.)(CR≥2)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6-bit), 61 pins |
| vstupné napätie | 3.3/5.0/8.0/-4.0/-8.0V (Typ.)(VSHD/VSHA/VDD/VSSD/VEE) |
| aplikácie | PDA |
