| Číslo dielu | NL4864HL11-01B |
| Značka | NLT |
| Veľkosť | 3.5 |
| Aplikácia | PDA |
| Rozhodnutie | 480×640 |
| Zloženie | LCM |
| Jas | 200 |
| CR | 180:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | NEC |
| panelový model | NL4864HL11-01B |
| typ panelu | LTPS TFT-LCD , LCM |
| veľkosť panelu | 3.5 inch |
| rozhodnutie | 480(RGB)×640 , VGA |
| režim zobrazenia | TN, Normally White, Transflective |
| aktívna oblasť | 53.28×71.04 mm |
| obrys | 63.5×85 mm |
| povrch | Clear, Hard coating (3H) |
| jas | 200 cd/m² (Typ.) |
| kontrastný pomer | 180:1 (Typ.)(Transmissive) |
| zobraziť farby | 262K (6-bit), CIE193140% |
| Doba odozvy | |
| pozorovací uhol | 30/30/30/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLED |
| signálové rozhranie | CMOS (1 ch, 6-bit), 45 pins |
| vstupné napätie | 3.0/3.0V (Typ.)(VCC/VCCIO) |
| aplikácie | PDA |
