| Číslo dielu | NL160120BC27-14 |
| Značka | NLT |
| Veľkosť | 21.3 |
| Aplikácia | DMPC |
| Rozhodnutie | 1600×1200 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 550:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | NEC |
| panelový model | NL160120BC27-14 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 21.3 inch |
| rozhodnutie | 1600(RGB)×1200 , UXGA |
| režim zobrazenia | SA-SFT, Normally Black, Transmissive |
| aktívna oblasť | 432×324 mm |
| obrys | 457×350 mm |
| povrch | Antiglare, Hard coating (2H) |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 550:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193172% |
| Doba odozvy | 11/9 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 40 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | DMPC |
