| Číslo dielu | M190A1-L07 |
| Značka | Innolux |
| Veľkosť | 19.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1440×900 |
| Zloženie | LCM |
| Jas | 380 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | CMO |
| panelový model | M190A1-L07 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 19.0 inch |
| rozhodnutie | 1440(RGB)×900 , WXGA+ |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 410.4×256.5 mm |
| obrys | 427.2×277.4×16.5 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 380 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Doba odozvy | 1.5/3.5 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
| FLC48SXC8V-11AA | Fujitsu | 19.0 | 1280×1024 |
| G190ETN01.0 | AUO | 19.0 | 1280×1024 |
| LM190E08-TLJ7 | LG Display | 19.0 | 1280×1024 |
| M190A1-L01 | Innolux | 19.0 | 1440×900 |
| M190A1-L02 | Innolux | 19.0 | 1440×900 |
| M190A1-L07 | Innolux | 19.0 | 1440×900 |
| M190A1-L0A | Innolux | 19.0 | 1440×900 |
| M190A1-L0G | Innolux | 19.0 | 1440×900 |
| M190MWW4 R2 | IVO | 19.0 | 1440×900 |
| R190EFE-L51 | Innolux | 19.0 | 1280×1024 |
| HR236WU3-301 | BOE | 23.6 | 1920×1080 |
| ITSX98 | IDTech | 18.1 | 1280×1024 |
| LM220WE1-TLM1 | LG Display | 22.0 | 1680×1050 |
| LM270WF7-SSB1 | LG Display | 27.0 | 1920×1080 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTM220MT12 | Samsung | 22.0 | 1680×1050 |
| M185B1-L02 | Innolux | 18.5 | 1366×768 |
| M185XW01 VF | AUO | 18.5 | 1366×768 |
| M215HW03 V1Q0 | AUO | 21.5 | 1920×1080 |
| TX38D12VC0CAA | KOE | 15.0 | 1024×768 |
