| Číslo dielu | MV238QUM-N20 |
| Značka | BOE |
| Veľkosť | 23.8 |
| Aplikácia | DMPC |
| Rozhodnutie | 3840×2160 |
| Zloženie | LCM |
| Jas | 300 |
| CR | 1000:1 |
| Farby | 1.07B |
| Podsvietenie | WLED |
| Rozhranie | eDP |
| značka panelu | BOE |
| panelový model | MV238QUM-N20 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 23.8 inch |
| rozhodnutie | 3840(RGB)×2160 , UHD |
| režim zobrazenia | ADS, Normally Black, Transmissive |
| aktívna oblasť | 527.04×296.46 mm |
| obrys | 545×323.4×12.5 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 1.07B (8-bit + Hi-FRC), sRGB75% |
| Doba odozvy | 14 (Typ.)(G to G) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 14S4PWLEDWithout Driver |
| signálové rozhranie | eDP (4 Lanes), 30 pins |
| vstupné napätie | 10.0V (Typ.) |
| aplikácie | DMPC |
