| Číslo dielu | NL256204AM15-02A |
| Značka | NLT |
| Veľkosť | 20.1 |
| Aplikácia | DMPC |
| Rozhodnutie | 2560×2048 |
| Zloženie | LCM |
| Jas | 850 |
| CR | 600:1 |
| Farby | Grayscale |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | NEC |
| panelový model | NL256204AM15-02A |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 20.1 inch |
| rozhodnutie | 2560(LCR)×2048 , QSXGA |
| režim zobrazenia | SA-SFT, Normally Black, Transmissive |
| aktívna oblasť | 399.36×319.49 mm |
| obrys | 423.4×343.5×45.5 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 850 cd/m² (Typ.) |
| kontrastný pomer | 600:1 (Typ.) |
| zobraziť farby | Grayscale (8-bit) |
| Doba odozvy | 15/15 (Typ.)(Tr/Td) |
| pozorovací uhol | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 12 pcsCCFLEmbedded (Inverter) |
| signálové rozhranie | LVDS (4 ch, 8-bit) |
| vstupné napätie | 12.0V (Typ.) |
| rohs: | |
| aplikácie | DMPC |
