| Číslo dielu | NL12876AC39-01 |
| Značka | NLT |
| Veľkosť | 23.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1280×768 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 350:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | NEC |
| panelový model | NL12876AC39-01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 23.0 inch |
| rozhodnutie | 1280(RGB)×768 , WXGA |
| režim zobrazenia | UA-SFT, Normally Black, Transmissive |
| aktívna oblasť | 501.12×300.672 mm |
| obrys | 528×326 mm |
| povrch | Hard coating (2H), Antireflection |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 350:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193172% |
| Doba odozvy | 10/13 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 12 pcsCCFLEmbedded (Inverter) |
| signálové rozhranie | LVDS (1 ch, 8-bit), 20 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
