| Číslo dielu | LSL080AL02-002 |
| Značka | Samsung |
| Veľkosť | 8.0 |
| Aplikácia | PAD |
| Rozhodnutie | 800×1280 |
| Zloženie | CELL |
| Jas | 0 |
| CR | 900:1 |
| Farby | 16.7M |
| Podsvietenie | No B/L |
| Rozhranie | MIPI |
| značka panelu | SAMSUNG |
| panelový model | LSL080AL02-002 |
| typ panelu | a-Si TFT-LCD , CELL |
| veľkosť panelu | 8.0 inch |
| rozhodnutie | 800(RGB)×1280 , WXGA |
| režim zobrazenia | PLS, Normally Black, Transmissive |
| aktívna oblasť | 107.64×172.224 mm |
| obrys | 112.64×181.824×0.69 mm |
| povrch | Glare (Haze 0%), Hard coating |
| hĺbka skla | 0.20+0.20 mm |
| priepustnosť | 6.6% (Typ.)(with Polarizer) |
| kontrastný pomer | 900:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 16 (Typ.)(Tr+Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| signálové rozhranie | MIPI (4 data lanes), 34 pins |
| vstupné napätie | 1.8/3.3V (Typ.)(DVDD/PVDD) |
| aplikácie | PAD |
