| Číslo dielu | HE101NA-02C |
| Značka | Innolux |
| Veľkosť | 10.1 |
| Aplikácia | PAD |
| Rozhodnutie | 1280×800 |
| Zloženie | CELL |
| Jas | 0 |
| CR | 700:1 |
| Farby | 16.7M |
| Podsvietenie | No B/L |
| Rozhranie | TTL |
| značka panelu | CHIMEI INNOLUX |
| panelový model | HE101NA-02C |
| typ panelu | a-Si TFT-LCD , CELL |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1280(RGB)×800 , WXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 216.96×135.6 mm |
| obrys | 224.21×145×1.43 mm |
| povrch | Glare (Haze 0%) |
| hĺbka skla | 0.50+0.50 mm |
| kontrastný pomer | 700:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 10/20 (Typ.)(Tr/Td) |
| pozorovací uhol | 75/70/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| signálové rozhranie | Parallel RGB (1 ch, 8-bit), 40 pins |
| vstupné napätie | 3.3/11.0/20.0/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikácie | PAD |
