| Číslo dielu | HV089WU1-1E0 |
| Značka | HYDIS |
| Veľkosť | 8.9 |
| Aplikácia | PAD |
| Rozhodnutie | 1920×1200 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 800:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | HYDIS |
| panelový model | HV089WU1-1E0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 8.9 inch |
| rozhodnutie | 1920(RGB)×1200 , WUXGA |
| režim zobrazenia | HFFS, Normally Black, Transmissive |
| aktívna oblasť | 191.52×119.7 mm |
| obrys | 203.5×135.9×5 mm |
| povrch | Antireflection |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC) |
| Doba odozvy | 30 (Typ.)(Tr+Td) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 7S5PWLEDWithout Driver |
| signálové rozhranie | MIPI (4 data lanes), 45 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
