| Číslo dielu | LS035Y8DX02A |
| Značka | SHARP |
| Veľkosť | 3.5 |
| Aplikácia | MPH |
| Rozhodnutie | 480×800 |
| Zloženie | LCM |
| Jas | 500 |
| CR | 500:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | SHARP |
| panelový model | LS035Y8DX02A |
| typ panelu | CG-Silicon , LCM |
| veľkosť panelu | 3.5 inch |
| rozhodnutie | 480(RGB)×800 , WVGA |
| režim zobrazenia | ASV, Normally Black, Transflective |
| aktívna oblasť | 45.36×75.6 mm |
| obrys | 51.16×86.45 mm |
| povrch | |
| jas | 500 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.)(Transmissive)10:1 (Typ.)(Reflective) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| Doba odozvy | 11/24 (Typ.)(Tr/Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 7S1PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| vstupné napätie | 1.8/2.8V (Typ.)(VDDIO/VCC) |
| aplikácie | MPH |
