| Číslo dielu | LQ070M1SX01 |
| Značka | SHARP |
| Veľkosť | 7.0 |
| Aplikácia | PAD |
| Rozhodnutie | 1200×1920 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 2000:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | SHARP |
| panelový model | LQ070M1SX01 |
| typ panelu | IGZO TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 1200(RGB)×1920 , WUXGA |
| režim zobrazenia | ASV, Normally Black, Transmissive |
| aktívna oblasť | 94.5×151.2 mm |
| obrys | 99.7×159.85×1.925 mm |
| povrch | Clear, Hard coating |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 2000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| Doba odozvy | 9/13 (Typ.)(Tr/Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 9S2PWLEDWithout Driver |
| signálové rozhranie | MIPI (2 data lanes), 71 pins |
| vstupné napätie | 1.8/3.0/5.5/-5.5V (Typ.)(VDDIO/VDD/VSP/VSN) |
| aplikácie | PAD |
