| Číslo dielu | B116HAT03.1 |
| Značka | AUO |
| Veľkosť | 11.6 |
| Aplikácia | PAD |
| Rozhodnutie | 1920×1080 |
| Zloženie | Assembly |
| Jas | 350 |
| CR | 800:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | eDP |
| značka panelu | AUO |
| panelový model | B116HAT03.1 |
| typ panelu | a-Si TFT-LCD , Assembly |
| veľkosť panelu | 11.6 inch |
| rozhodnutie | 1920(RGB)×1080 , FHD |
| aktívna oblasť | 256.32×144.18 mm |
| obrys | 288.8×176.8×8.25 mm |
| povrch | Hard coating (8H) |
| jas | 350 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193152% |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| signálové rozhranie | eDP (2 Lanes), 30 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
| B116AW02 V0 | AUO | 11.6 | 1024×600 |
| B116HAN03.1 | AUO | 11.6 | 1920×1080 |
| B116HAT03.1 | AUO | 11.6 | 1920×1080 |
| B116XTT01.0 | AUO | 11.6 | 1366×768 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| LTN116AT07-B01 | Samsung | 11.6 | 1366×768 |
| N116BGE-EB2 Rec.C3 | Innolux | 11.6 | 1366×768 |
| N116BGE-LB1 | Innolux | 11.6 | 1366×768 |
| NT116WHM-N22 | BOE | 11.6 | 1366×768 |
| VVX11F019G00 | Panasonic | 11.6 | 1920×1080 |
| CLAA101WJ01 | CPT | 10.1 | 1366×768 |
| HV089WU1-1E0 | HYDIS | 8.9 | 1920×1200 |
| HV121P01-101 | HYDIS | 12.1 | 1400×1050 |
| HV121WX5-111 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-100 | HYDIS | 12.1 | 1280×800 |
| LD070WX3-SL01 | LG Display | 7.0 | 800×1280 |
| LT070ME05000 | JDI | 7.0 | 1200×1920 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.C2 | Innolux | 8.0 | 800×1280 |
| TPF0702001N | JDI | 7.0 | 1200×1920 |
