| Číslo dielu | LQ070Y3LW01 |
| Značka | SHARP |
| Veľkosť | 7.0 |
| Aplikácia | IA |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 360 |
| CR | 800:1 |
| Farby | 16.2M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | SHARP |
| panelový model | LQ070Y3LW01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 800×480(RGB) , WVGA |
| režim zobrazenia | ASV, Normally Black, Transmissive |
| aktívna oblasť | 152.4×91.44 mm |
| obrys | 163.2×104×9.5 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 360 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 16.2M (6-bit + FRC) |
| Doba odozvy | 35 (Typ.)(Tr+Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 7S2PWLEDWithout Driver |
| signálové rozhranie | LVDS (1 ch, 8-bit), 20 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | IA |
