| Číslo dielu | LPM055A138A |
| Značka | JDI |
| Veľkosť | 5.5 |
| Aplikácia | MPH |
| Rozhodnutie | 1440×2560 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 950:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | JDI |
| panelový model | LPM055A138A |
| typ panelu | LTPS TFT-LCD , LCM |
| veľkosť panelu | 5.5 inch |
| rozhodnutie | 1440(RGB)×2560 , Quad-HD |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 68.04×120.96 mm |
| obrys | 70.94×128.26×1.5 mm |
| povrch | Hard coating (3H) |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 950:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193170% |
| Doba odozvy | 20 (Typ.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 7S2PWLEDWithout Driver |
| signálové rozhranie | MIPI (2 ch, 4 data lanes), 50 pins |
| vstupné napätie | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| aplikácie | MPH |
