| Číslo dielu | EE050NA-04A |
| Značka | Innolux |
| Veľkosť | 5.0 |
| Aplikácia | VDP |
| Rozhodnutie | 640×480 |
| Zloženie | CELL |
| Jas | 0 |
| CR | 500:1 |
| Farby | 16.7M |
| Podsvietenie | No B/L |
| Rozhranie | TTL |
| značka panelu | CHIMEI INNOLUX |
| panelový model | EE050NA-04A |
| typ panelu | a-Si TFT-LCD , CELL |
| veľkosť panelu | 5.0 inch |
| rozhodnutie | 640(RGB)×480 , VGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 101.568×76.176 mm |
| obrys | 109.55×85.86 mm |
| povrch | Antiglare |
| hĺbka skla | 0.63+0.63 mm |
| priepustnosť | 5.5% (Typ.)(with Polarizer) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 10/15 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| signálové rozhranie | Parallel RGB (1 ch, 8-bit), 50 pins |
| vstupné napätie | 3.3/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikácie | VDP |
