| Číslo dielu | TM050JVZG28 |
| Značka | Tianma |
| Veľkosť | 5.0 |
| Aplikácia | MPH |
| Rozhodnutie | 720×1280 |
| Zloženie | Assembly |
| Jas | 300 |
| CR | 800:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | TIANMA |
| panelový model | TM050JVZG28 |
| typ panelu | a-Si TFT-LCD , Assembly |
| veľkosť panelu | 5.0 inch |
| rozhodnutie | 720(RGB)×1280 , WXGA |
| aktívna oblasť | 62.9×110.4 mm |
| obrys | 71.1×132.85 mm |
| povrch | |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193170% |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| signálové rozhranie | MIPI (4 data lanes), 31 pins |
| vstupné napätie | 1.8/2.8V (Typ.)(IOVCC/VCI) |
| aplikácie | MPH |
