| Číslo dielu | CLAA069JA11CW |
| Značka | CPT |
| Veľkosť | 7.0 |
| Aplikácia | CNS |
| Rozhodnutie | 480×234 |
| Zloženie | LCM |
| Jas | 500 |
| CR | 400:1 |
| Farby | Full color |
| Podsvietenie | CCFL |
| Rozhranie | Analog |
| značka panelu | CPT |
| panelový model | CLAA069JA11CW |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 480(RGB)×234 |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 156.24×82.368 mm |
| obrys | 167×93 mm |
| povrch | Antiglare |
| jas | 500 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | Full color |
| Doba odozvy | 10/20 (Typ.)(Tr/Td) |
| pozorovací uhol | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhranie | TFT Specific Analog RGB, 30 pins |
| vstupné napätie | 5.0/5.0/18.0/-6.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikácie | CNS |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA061LA0DCW | CPT | 6.1 | 800×480 |
| CLAA069JA11CW | CPT | 7.0 | 480×234 |
| CLAA069LA0FCW | CPT | 7.0 | 800×480 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| CLAA069LB02CW | CPT | 7.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| CLAA069LC01XW | CPT | 7.0 | 800×480 |
| 70WVW2A | SII | 7.0 | 800×480 |
| A061FW01 V0 | AUO | 6.1 | 480×234 |
| AT070TN84 V.1 | Innolux | 7.0 | 800×480 |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| CLAA070NJ01CW | CPT | 7.0 | 1024×600 |
| L5F30369P01 | SANYO | 6.5 | 800×480 |
| LB070WQ7-TD02 | LG Display | 7.0 | 480×234 |
| LQ065T9BR54U | SHARP | 6.5 | 400×240 |
| LTE052T-4301-1 | TPO | 5.0 | 320×234 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
