| Číslo dielu | CLAA061LA0BCW |
| Značka | CPT |
| Veľkosť | 6.1 |
| Aplikácia | CNS |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 500 |
| CR | 400:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | CPT |
| panelový model | CLAA061LA0BCW |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 6.1 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 136.2×72 mm |
| obrys | 149×82.9×5.2 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 500 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193170% |
| Doba odozvy | 20 (Typ.)(Tr+Td) |
| pozorovací uhol | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 3S7PWLEDWithout Driver |
| signálové rozhranie | TTL (1 ch, 6-bit), 60 pins |
| vstupné napätie | 3.3/9.2/18/-6V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikácie | CNS |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA061LA0DCW | CPT | 6.1 | 800×480 |
| CLAA069JA11CW | CPT | 7.0 | 480×234 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| CLAA069LA0FCW | CPT | 7.0 | 800×480 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| CLAA069LB02CW | CPT | 7.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| 70WVW1T | SII | 7.0 | 800×480 |
| 70WVW4A | SII | 7.0 | 800×480 |
| A070VW05 V0 | AUO | 7.0 | 800×480 |
| G121S1-L02 | Innolux | 12.1 | 800×600 |
| LA050WQ1-TD01 | LG Display | 5.0 | 480×272 |
| LB070WQ4-TM06 | LG Display | 7.0 | 480×234 |
| LQ070Y5DG11 | SHARP | 7.0 | 800×480 |
| LQ080Y5CGQ2 | SHARP | 8.0 | 800×480 |
| LQ088H9DR01U | SHARP | 8.8 | 640×240 |
| NL3224AC35-06 | NLT | 5.5 | 320×240 |
