| Číslo dielu | 70WVW2A |
| Značka | SII |
| Veľkosť | 7.0 |
| Aplikácia | CNS |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 400:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | SII |
| panelový model | 70WVW2A |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 152.4×91.44 mm |
| obrys | 165×105.8×3.65 mm |
| povrch | Antiglare |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193145% |
| Doba odozvy | 5/11 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/55/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 8S3PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | CNS |
| 70WVW1A | SII | 7.0 | 800×480 |
| 70WVW1T | SII | 7.0 | 800×480 |
| 70WVW2A | SII | 7.0 | 800×480 |
| 70WVW2T | SII | 7.0 | 800×480 |
| 70WVW3A | SII | 7.0 | 800×480 |
| 70WVW3T | SII | 7.0 | 800×480 |
| 70WVW4A | SII | 7.0 | 800×480 |
| 70WVW5A | SII | 7.0 | 800×480 |
| A070FW03 VD | AUO | 7.0 | 480×234 |
| C070VW02 V0 | AUO | 7.0 | 800×480 |
| 70WVW2A | SII | 7.0 | 800×480 |
| C070VAN01.3 | AUO | 7.0 | 800×480 |
| CLAA090NA06CW | CPT | 9.0 | 1024×600 |
| FG0700G3DSSWBGL4 | Data Image | 7.0 | 800×480 |
| G104V1-T01 | Innolux | 10.4 | 640×480 |
| L5F30818P01 | Epson | 6.5 | 800×480 |
| LQ070T5GC01 | SHARP | 7.0 | |
| LQ6BW506 | SHARP | 5.8 | 400×234 |
| ND078-101A1 | SEBO | 7.8 | 1280×400 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
