| Číslo dielu | BP070WX1-300 |
| Značka | BOE |
| Veľkosť | 7.0 |
| Aplikácia | PAD |
| Rozhodnutie | 800×1280 |
| Zloženie | LCM |
| Jas | |
| CR | |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | BOE |
| panelový model | BP070WX1-300 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 800(RGB)×1280 , WXGA |
| režim zobrazenia | AFFS, Normally Black, Transmissive |
| aktívna oblasť | 94.2×150.72 mm |
| obrys | 99.7×160.93×3.8 mm |
| povrch | Hard coating (3H), Antireflection |
| jas | |
| kontrastný pomer | |
| zobraziť farby | 16.7M (6-bit + Hi-FRC), CIE193150% |
| Doba odozvy | 30 (Typ.)(Tr+Td) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 5S4PWLEDWithout Driver |
| signálové rozhranie | MIPI, 34 pins |
| vstupné napätie | 1.8/3.3V (Typ.)(IOVCC/VDD) |
| aplikácie | PAD |
