| Číslo dielu | BP070WS1-400 |
| Značka | BOE |
| Veľkosť | 7.0 |
| Aplikácia | PAD |
| Rozhodnutie | 1024×600 |
| Zloženie | LCM |
| Jas | 350 |
| CR | 900:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | BOE |
| panelový model | BP070WS1-400 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 1024(RGB)×600 , WSVGA |
| režim zobrazenia | ADS, Normally Black, Transmissive |
| aktívna oblasť | 153.6×90 mm |
| obrys | 162.8×102.9×4.2 mm |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 350 cd/m² (Typ.) |
| kontrastný pomer | 900:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC), CIE193152% |
| Doba odozvy | 30 (Typ.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 5S4PWLEDEmbedded (LED Driver) |
| signálové rozhranie | MIPI (4 data lanes), 31 pins |
| vstupné napätie | 3.7V (Typ.) |
| aplikácie | PAD |
