| Číslo dielu | TX43D14VC0CAB |
| Značka | KOE |
| Veľkosť | 17.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1280×1024 |
| Zloženie | LCM |
| Jas | 230 |
| CR | 400:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | HITACHI |
| panelový model | TX43D14VC0CAB |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 17.0 inch |
| rozhodnutie | 1280(RGB)×1024 , SXGA |
| režim zobrazenia | IPS-Pro, Normally Black, Transmissive |
| aktívna oblasť | 337.92×270.336 mm |
| obrys | 368×306 mm |
| povrch | Antiglare |
| jas | 230 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC) |
| Doba odozvy | 20/20 (Typ.)(Tr/Td) |
| pozorovací uhol | |
| frekvencia | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
