| Číslo dielu | B170UW02 V0 |
| Značka | AUO |
| Veľkosť | 17.0 |
| Aplikácia | NBPC |
| Rozhodnutie | 1920×1200 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 600:1 |
| Farby | 262K |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | B170UW02 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 17.0 inch |
| rozhodnutie | 1920(RGB)×1200 , WUXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 367.2×229.5 mm |
| obrys | 382.2×247.5×7 mm |
| tvarový štýl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| povrch | Glare (Haze 0%), Hard coating (4H) |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 600:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193172% |
| Doba odozvy | 8 (Typ.)(Tr+Td) |
| pozorovací uhol | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 2 pcsCCFL |
| signálové rozhranie | LVDS (2 ch, 6-bit), 30 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NBPC |
