| Číslo dielu | M170ETN01.0 |
| Značka | AUO |
| Veľkosť | 17.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1280×1024 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | M170ETN01.0 3 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 17.0 inch |
| rozhodnutie | 1280(RGB)×1024 , SXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 337.92×270.336 mm |
| obrys | 358.5×296.5×15.8 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC) |
| Doba odozvy | 3.5/1.5 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
| M170E5-L0A | Innolux | 17.0 | 1280×1024 |
| M170EG01 V0 | AUO | 17.0 | 1280×1024 |
| M170EG01 V5 | AUO | 17.0 | 1280×1024 |
| M170EG01 V8 | AUO | 17.0 | 1280×1024 |
| M170EG01 V9 | AUO | 17.0 | 1280×1024 |
| M170EG01 VH | AUO | 17.0 | 1280×1024 |
| M170EGE-L20 | Innolux | 17.0 | 1280×1024 |
| M170EN04 V6 | AUO | 17.0 | 1280×1024 |
| M170ETN01.0 | AUO | 17.0 | 1280×1024 |
| M170EU01 V0 | AUO | 17.0 | 1280×1024 |
| LM185WH1-TLA1 | LG Display | 18.5 | 1366×768 |
| LM215DT8A | PANDA | 21.5 | 1920×1080 |
| LM230WF5-TLD5 | LG Display | 23.0 | 1920×1080 |
| LTM170EU-A01 | Samsung | 17.0 | 1280×1024 |
| LTM215HL01 | Samsung | 21.5 | 1920×1080 |
| LTM300M1-P02 | Samsung | 30.0 | 2560×1600 |
| M236H3-LA2 | Innolux | 23.6 | 1920×1080 |
| M240J1-L03 | Innolux | 24.0 | 1920×1200 |
| MV190E0M-N10 | BOE | 19.0 | 1280×1024 |
| TD170WGCA1 | TPO | 17.0 | 1280×1024 |
