| Číslo dielu | NL128102BC23-03 |
| Značka | NLT |
| Veľkosť | 15.4 |
| Aplikácia | DMPC |
| Rozhodnutie | 1280×1024 |
| Zloženie | LCM |
| Jas | 240 |
| CR | 250:1 |
| Farby | 16.2M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | NEC |
| panelový model | NL128102BC23-03 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 15.4 inch |
| rozhodnutie | 1280(RGB)×1024 , SXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 305.28×244.224 mm |
| obrys | 340×269 mm |
| povrch | Hard coating (3H), Antireflection |
| jas | 240 cd/m² (Typ.) |
| kontrastný pomer | 250:1 (Typ.) |
| zobraziť farby | 16.2M (6-bit + FRC), CIE193160% |
| Doba odozvy | 6/41 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 50 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | DMPC |
| LTN154P1-L01 | Samsung | 15.4 | 1680×1050 |
| LTN154W1-L01 | Samsung | 15.4 | 1440×900 |
| NL128102AC23-01 | NLT | 15.4 | 1280×1024 |
| NL128102AC28-07 | NLT | 18.1 | 1280×1024 |
| NL128102AC29-17 | NLT | 19.0 | 1280×1024 |
| NL128102BC23-03 | NLT | 15.4 | 1280×1024 |
| NL128102BC29-01 | NLT | 19.0 | 1280×1024 |
| NL128102BC29-01B | NLT | 19.0 | 1280×1024 |
| NL128102BC29-01C | NLT | 19.0 | 1280×1024 |
| NL128102BM29-05A | NLT | 19.0 | 1280×1024 |
| LC215DTCA | PANDA | 21.5 | 1920×1080 |
| LM150X08-A4KD | LG Display | 15.0 | 1024×768 |
| LM220WE1-TLB2 | LG Display | 22.0 | 1680×1050 |
| LM270WF5-SSA1 | LG Display | 27.0 | 1920×1080 |
| LQ150X1LCD3 | SHARP | 15.0 | 1024×768 |
| LTM190E4-L03 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L21 | Samsung | 19.0 | 1280×1024 |
| M195FGE-L20 | Innolux | 19.5 | 1600×900 |
| M215HJJ-L30 Rev.B1 | Innolux | 21.5 | 1920×1080 |
| NL160120BC27-09 | NLT | 21.3 | 1600×1200 |
