| Číslo dielu | PW056XU1 |
| Značka | E Ink |
| Veľkosť | 5.5 |
| Aplikácia | VDP |
| Rozhodnutie | 480×234 |
| Zloženie | LCM |
| Jas | 350 |
| CR | 350:1 |
| Farby | Full color |
| Podsvietenie | CCFL |
| Rozhranie | Analog |
| značka panelu | PVI |
| panelový model | PW056XU1 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.5 inch |
| rozhodnutie | 480(RGB)×234 |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 121.68×68.45 mm |
| obrys | 136×82.6×6.1 mm |
| povrch | Antiglare |
| jas | 350 cd/m² (Typ.) |
| kontrastný pomer | 350:1 (Typ.) |
| zobraziť farby | Full color |
| Doba odozvy | 15/25 (Typ.)(Tr/Td) |
| pozorovací uhol | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhranie | TFT Specific Analog RGB, 30 pins |
| vstupné napätie | 3.3/3.3/5.0/17.0/12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VEE) |
| aplikácie | VDP |
