| Číslo dielu | NL192108AC10-01D |
| Značka | NLT |
| Veľkosť | 9.0 |
| Aplikácia | IA |
| Rozhodnutie | 1920×1080 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 700:1 |
| Farby | 262K/16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | NLT |
| panelový model | NL192108AC10-01D |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 9.0 inch |
| rozhodnutie | 1920(RGB)×1080 , FHD |
| režim zobrazenia | UA-SFT, Normally Black, Transmissive |
| aktívna oblasť | 198.72×111.78 mm |
| obrys | 214.6×130×9.6 mm |
| povrch | Antiglare (Haze 41%), Hard coating (2H), Antireflection |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 700:1 (Typ.) |
| zobraziť farby | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| Doba odozvy | 13/12 (Typ.)(Tr/Td) |
| pozorovací uhol | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (2 ch, 6/8-bit), 50 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | IA |
